FEATURES ● Type "K" Thermocouple Input
● Room Temperature Compensated
● Switchable Resolution 0.1°/1°
● Aux output JACKS
● With °C & °F switching
● T1 & T2 dual points display(1303)
● Max Hold Function
● T1-T2 differential measurement(1303)
● Data Hold Function
● Flip-up stand

SPECIFICATIONS :

• Measuring Range -50°C -1300°C; -50°F -1999°F
• Sensor : K Type Thermocouple
• Input : Single Channel(TES-1300)/Dual Channel(TES-1303)
• Resolution :
  -50°C ~ 199.9°C ...0.1°C
  -50°F+ 199.9°F...0.1°F (Others 1°C/1°F)
• Accuracy :
  -50°C to 199.9°C...0.3% rdg + 1°C
  -50°F to 199.9°F...0.3% rdg + 2°F
  -50°C to 1000°C...0.5% rdg + 1°C
  -50°F to 1999°F. ..0.5% rdg + 2°F
  1000°C to 1300°C..0.75% rdg + 1°C (apply to mainframe only at 23°C ±5°C)
• Auxilitary Outputs:
  (for Data Recording) 1mV/ °C (°F).....at 0.1°C /0.1°F range 0.1mV/ °C (°F).....at 1°C /1°F range
• Temperature Coefficient : Less that 0.1 times the applicable accuracy specification per °C (°F)
• Input Protection :
  60V DC or 24 Vrms AC maximum input voltage on any combination of input Connector.
• Sampling Rate : 2.5 times/sec
• Operating Conditions : 0°C - 50°C (32°F-122°F), 10~80% R.H.
• Power Source : one 9V battery (006P or IEC6F22)
• Size : 135mm(L)x72mm(W)x31mm(H)
• Weight : 235g
• Accessories : Battery, Instruction Manual
