FEATURES ● Sensitive for low/high air velocity
● Economic Design
● Detacheable 52mm (diameter) Vane Head
● 2 meters coiled cable/back mounting screw for long extension
● Low Power Consumption(6mA)
● Data Hold Function
● Max Hold for temperature

ELECTRICAL SPECIFICATIONS : (23°0 ± 5°C)

• Air Velocity: AVM-01/AVM-03(4 ranges)

Measurement	Range	Resolution	Accuracy
M/S	0-45.0	0.1	±3% or 0.1
KNOTS	0-88.0	0.1	±3% or 0.1
ft/min	0-8800	10	±3% or 10
Km/hr	0-140.0	0.1	±3% or 0.1

• Optional Range : MPH

Measurement	Range	Resolution	Accuracy
MPH	0-100.0	0.1	±3% or 0.1

Remakes :	Conversion :
M/S: meter per second KNOTS : nautical miles per hour ft/min : feet per minute Km/hr : kilometers per hour mph : miles per hour	1M/S = 3.60 Km/H 1M/S = 2.24 MPH 1M/S = 1.944 KNOTS 1M/S = 196.87 ft/min 1KNOTS = 101.28 ft/min

• Temperature : AVM-03 only

Measurement	Range	Resolution	Accuracy
°C	0-60.0	0.1	±0.8
°F	32.0-140.0	0.1	±1.5

GENERAL SPECIFICATIONS :

• Operating Temperature : 10°C-50°C
• Operating Pressure : 500mB-2bar
• Display : Large 3-1/2 digits LCD
• Power Source : 1pc of 9V Battery
• Dimension : Meter : 168mm x 88mm x 26.2mm / Vane : 132mm x 66mm x 29.2
• Weight : 350g
• Accessories : Carrying Case, 9V Battery, Instruction Manual.
