다양한 고체에 적용:특히 고온의 고체에 적용, 미세한 분체, fly ash의 취합장에 적용가능.
| DESCRIPTION | SRF-600 Series | SRF-900 Series | RF-600-10U | |
|---|---|---|---|---|
| TYPE | Radio Frequency Level Sensor | Level Switch Controller | ||
| POWER SUPPLY | DC24V(DC16-30V)2-Wire | AC110/220V,60Hz | AC110/220V,60Hz | |
| SIGNAL | NON DETECTION | DC9~10mA± 1 | "NO" Open | INPUT:4~11mA |
| DETECTION | DC19~20mA± 1 | "NO" Close | INPUT:17~21mA | |
| OUTPUT IMPEDANCE | 450Ω(DC24V) | - | - | |
| CONTACT | - | 1DPDT,AC250V/5A | 1DPDT,AC250V/5A | |
| SENSITIVITY RANGE | 5~30pF | - | ||
| DELAY TIME | 0.5,2,4,6SEC | 0.5~10 Sec | ||
| EXPLOSION PROOF | Ex d ⅡB T4 | - | ||
| PROBE MATERIAL | SUS304,SUS316,P.P.S,Ceramic,Teflon(or Kynar)Coating | - | ||
| TEMPERATURE | ELECTRONICS | 0~+60℃ | 0~+60℃ | |
| PROBE | +500℃ Max. | - | ||
| MOUNTING | PT1", PT1½", JIS 5k 65A Flange | Rack Mount | ||
| FUNCTION | Selecable H/L Alarm,Operating Test Switch,Sensitivity Adjustment | 10 Points Detection | ||
| CABLE DISTANCE | Head & Probe Separation Distance 20m Max. | 1,500m | ||
